Instrumentation Multi-Pair

Individually screened pairs, overall screen, for analogue measurement loops and instrumentation systems in plants and infrastructure, 300 V rating.

customer spec

Request a quotation

RangeControl & Instrumentation Cable

Standardscustomer spec

To quoteSend a specification, BOQ or line item — we confirm construction, standard and lead time.

Instrumentation Multi-Pair — conceptual illustration

Overview

Instrumentation Multi-Pair: product guide

Instrumentation multi-pair cable organises analogue measurement circuits into screened pairs. The catalogue describes a 300 V range with individual and overall screening.

Applications

Typical applications

Use 1Plant analogue measurement loops

Use 2Infrastructure instrumentation systems

SelectionSpecify pairs and screens from the instrument schedule, keeping circuit identification consistent with the drawings.

Standards

Standards and project specifications

Other catalogue references to confirm for the selected configuration: customer spec.

State the required standard, edition and project specification in the enquiry. Applicability depends on the selected construction and installation. A catalogue reference does not establish certification or approval for every model; identify any required certificates and test records for review.

Quotation requirements

What to send for quotation

Item 1Pair count, conductor size and circuit voltage

Item 2Individual/overall screen arrangement and pair identification

Item 3Instrument schedule, route conditions and lengths

SpecificationAttach the BOQ, drawings or schedule, required standard and edition, and any acceptance or documentation requirements.

DeliveryState quantities, destination and requested delivery date. Include packing or handling constraints; availability and lead time are subject to quotation.

FAQ

Frequently asked questions

Why provide an instrument or loop schedule?

It identifies the circuits, pair allocation and screening needs. This helps define the requested cable construction without relying on a generic multi-pair description.

What should accompany an enquiry?

Send the product requirements listed above with your specification or BOQ. Mark any items still to be decided so that construction, documentation and delivery requirements can be reviewed before quotation.

Request a Quote

Discuss your Instrumentation Multi-Pair requirements. Include the application, specification and quantities with your enquiry.
