HMI Cantilever Arms & Operator Stations: product guide

HMI cantilever arms and operator stations provide mounting arrangements for machine interfaces. Arm geometry, mounting points and interface equipment define the assembly.

Applications

Typical applications

Use 1Machine operator interfaces

Use 2Pendant control points

Use 3Desk-type operator stations

SelectionCoordinate arm geometry and interface equipment dimensions with cable routing and operator access.

Standards

Standards and project specifications

Other catalogue references to confirm for the selected configuration: project spec; IP65.

State the required standard, edition and project specification in the enquiry. Applicability depends on the selected construction and installation. A catalogue reference does not establish certification or approval for every model; identify any required certificates and test records for review.

Quotation requirements

What to send for quotation

Item 1HMI dimensions, cut-outs, equipment mass and mounting points

Item 2Arm reach, articulation, entry route and station arrangement

Item 3Operating environment and protection requirements

SpecificationAttach the BOQ, drawings or schedule, required standard and edition, and any acceptance or documentation requirements.

DeliveryState quantities, destination and requested delivery date. Include packing or handling constraints; availability and lead time are subject to quotation.

FAQ

Frequently asked questions

What is needed to define a cantilever-arm system?

Provide the interface dimensions, installed mass, reach and mounting details. These inputs allow the required arrangement to be reviewed with the enclosure and cable routing.

What should accompany an enquiry?

Send the product requirements listed above with your specification or BOQ. Mark any items still to be decided so that construction, documentation and delivery requirements can be reviewed before quotation.

Request a Quote

Discuss your HMI Cantilever Arms & Operator Stations requirements. Include the application, specification and quantities with your enquiry.
